SIMODUAL2 Pipe modules PE/PE Double-containment pipe
Order no. 010025240
Material internal/external
PE/PE
SDR1/SDR2 internal/external
11/17
d1 mm
32
d2 mm
90
e1 mm
3.0
e2 mm
5.4
Weight kg/m
1.924
Colour
black/black
Product no.
010025240
Stock availability
Available on request
Areas of use
- Chemical installations
- Pharmaceuticals and bioindustry
- Food production
Processing
SIMODUAL Data sheet
SIMODUAL² Product Range Brochures
SIMODUAL² Pipes & Fittings
PDF | 3.56 MB
SIMODUAL² Industrial Double-Containment Piping System - Dual pipes for double the protection Brochures
Double-walled piping systems are recommended for the transport of any hazardous substances. To address this need, SIMONA has developed the SIMODUAL2 Double-Containment Piping System as an innovative, all-inclusive system with integrated anchor points.
PDF | 1.21 MB
SIMODUAL² double containment piping system for industrial applications Videos
Double-containment pipe
Double-containment pipe fitting - bend
Double-containment pipe fitting - bend, extended
Double-containment pipe fitting - fixing point for pipe clamps
Double-containment pipe fitting - leak adaptor piece
Double-containment pipe fitting - reducer
Double-containment pipe fitting - tee
Double-containment pipe fitting - transition fitting
